GFRP (Fiberglass Reinforced Polymer) Rebar is a spiral wrapped structural reinforcing rod, it is one kind of composite material in market, Fiber reinforced composite is made of high performance fiber, synthetic resin (epoxy resin, vinyl resin, unsaturated polyester resin, etc.) matrix and curing agent. The fiber used are continuous fiber with high strength and high stiffness, FRP rebar can be used as an alternative to conventional steel reinforcement in structural concrete.
Product name: GRP/ FRP Rebar
Material: FRP/GRP
Color: Green or Customized Certificate:JG/T406-2013
Original: China
Loading Port: Tianjin,Qingdao,Shanghai.
Specification
Fiberglass rebar have become a material for replacing steel bars in reinforced concrete structures, and have good corrosion resistance and electromagnetic neutrality. Glass Fiber reinforcement polymer, also called Glass Fiber Reinforced Plastic(GFRP), is a new kind of composite material which glass fiber as reinforcement material,combines with epoxy resin and curing agent.
- Material: FRP/GRP
- Diameter: 3mm--40mm
- Color: Green or Customized
- Length: 6m, 12m or Customized
- Application: Civil construction
- Ultimate share strength:More than 150Mpa
- Modulus: 40Gpa
No | Diameter (mm) | Ultimate tensile load(KN) | Cross section (mm2) | Ultimate tensile strength (MPa) | Modulus of elasticity (GPa) | Ultimate shear strength (MPa) | Weight (g/m) | ||||
UP(1) | UP(2) | UP (1) | UP(2) | UP(1) | UP (2) | UP (1) | UP(2) | ||||
1 | 8 | 30 | 54 | 50.3 | 50 | 600 | 1080 | ≥40 | ≥110 | ≥150 | 105 |
2 | 10 | 47 | 67 | 78.5 | 73 | 923 | ≥40 | ≥110 | ≥150 | 165 | |
3 | 12 | 68 | 93 | 113 | 103 | 903 | ≥40 | ≥110 | ≥150 | 240 | |
4 | 14 | 80 | 118 | 133 | 134 | 880 | ≥40 | ≥110 | ≥150 | 280 | |
5 | 16 | 97 | 152 | 177 | 180 | 550 | 842 | ≥40 | ≥110 | ≥150 | 370 |
6 | 18 | 125 | 207 | 227 | 248 | 550 | 833 | ≥40 | ≥110 | ≥150 | 460 |
7 | 20 | 156 | 220 | 284 | 278 | 550 | 792 | ≥40 | ≥110 | ≥150 | 560 |
8 | 22 | 190 | 277 | 346 | 355 | 550 | 780 | ≥40 | ≥110 | ≥150 | 700 |
9 | 25 | 226 | 342 | 452 | 452 | 500 | 757 | ≥40 | ≥110 | ≥150 | 950 |
10 | 28 | 287 | 417 | 573 | 590 | 500 | 7071 | ≥40 | ≥110 | ≥150 | 1220 |
11 | 30 | 331 | 457 | 661 | 671 | 500 | 681 | ≥40 | ≥110 | ≥150 | 1350 |
12 | 32 | 378 | 497 | 755 | 740 | 500 | 672 | ≥40 | ≥110 | ≥150 | 1550 |
13 | 36 | 433 | 585 | 962 | 961 | 450 | 609 | ≥40 | ≥110 | ≥150 | 2040 |
14 | 40 | 538 | 640 | 1195 | 1190 | 450 | 538 | ≥40 | ≥110 | ≥150 | 2540 |
No | Diameter (mm) | Ultimate tensile load(KN) | Cross section (mm2) | Ultimate tensile strength (MPa) | Modulus of elasticity (GPa) | Ultimate shear strength (MPa) | Weight (g/m) | ||||||
EP | VEI | EP | VE | EP | VE | EP | VE | EP | VE | EP | VE | ||
1 | 6 | 28 | 28 | 28 | 28 | 1000 | 1000 | ≥50 | ≥40 | ≥150 | 60 | 60 | |
2 | 8 | 50 | 50 | 50.3 | 50 | 1000 | 1000 | 105 | 105 | ||||
3 | 10 | 79 | 69 | 78.5 | 73 | 1000 | 950 | 165 | 165 | ||||
4 | 12 | 113 | 98 | 113 | 103 | 1000 | 950 | 240 | 240 | ||||
5 | 14 | 120 | 121 | 133 | 134 | 900 | 900 | 280 | 280 | ||||
6 | 16 | 159 | 162 | 177 | 180 | 900 | 900 | 370 | 370 | ||||
7 | 18 | 204 | 211 | 227 | 248 | 900 | 850 | 460 | 460 | ||||
8 | 20 | 256 | 236 | 284 | 278 | 900 | 850 | 560 | 560 | ||||
9 | 22 | 311 | 284 | 346 | 355 | 900 | 800 | 700 | 700 | ||||
10 | 25 | 407 | 362 | 452 | 452 | 900 | 800 | 950 | 950 | ||||
11 | 28 | 458 | 443 | 573 | 590 | 800 | 750 | 1220 | 1220 | ||||
12 | 30 | 529 | 518 | 661 | 690 | 800 | 750 | 1350 | 1350 | ||||
13 | 32 | 604 | 518 | 755 | 740 | 800 | 700 | 1550 | 1550 | ||||
14 | 36 | 770 | 673 | 962 | 961 | 800 | 700 | 2040 | 2040 | ||||
15 | 40 | 956 | 774 | 1195 | 1190 | 800 | 650 | 2540 | 2540 |
Advantage
- Low specific gravity;
- High strength;
- Strong corrosion resistance;
- Easy to cut;
- No alkaline;
- Non conductive;
- Low thermal conductivity.
Photo Reference
Application
- Widely used in highways, bridges, airports, terminals, stations, water conservancy projects, underground engineering and other fields
- Suitable for corrosive environments such as sewage treatment plants, chemical plants, electrolysis tanks, manhole covers, and coastal defense projects.
- Suitable for military engineering, confidential engineering, special engineering, etc.
Process
Fiberglass reinforced plastic (FRP), also known as GFRP, is fiber reinforced plastic, which generally refers to glass fiber reinforced unsaturated polyester, epoxy resin and phenolic resin matrix. Reinforced plastics reinforced with glass fiber or its products are called glass fiber reinforced plastics or FRP, which are different from tempered glass
FRP is a composite material that has developed rapidly in recent decades. 70% of fiberglass production is used to make fiberglass. FRP has high hardness and is much lighter than steel. Jets are used as fuel tanks and pipes, which can reduce the weight of the aircraft.
FRP is easy to process, not rusted and not rotten, and does not require paint. FRP is widely used in my country to manufacture various small motor boats, lifeboats, yachts and automobile manufacturing, saving a lot of steel. As FRP is a composite material, its performance adapts to a wide range, and the market development prospect is broad.
After more than 40 years of development, In China FRP industry has been successfully applied to various fields of the national economy and played an important role in economic construction.
FRP bolts are mainly made of glass fiber yarn, resin, curing agent and other materials. In the process of finishing the machining, many different processes are also used, such as extrusion, drawing and high temperature curing, and the machined shape is full thread.
FRP Rebar Accessories
Normal accessories of FRP rebar include FRP Plate, FRP Nut, Steel Plate, Steel Nut, FRP Coupler, Drill bit ect.
Surface Treatment
According to the surface form of glass fiber reinforcement, it can be divided into fully threaded surface and sand-coated (sand-blasted) surface. The bond strength of GFRP bars and concrete is different with different surface forms, which can be selected according to customer requirements.
- -Sand coated
- -Wrapped and sand coated (Spring wood)
- -Plain
- -Ribbed
It also has type of hollow and solid.
FAQ
● What is FRP Rebar?
● What is GFRP Rebar?
● What is BFRP Rebar?
● What is CFRP Rebar?
● What is AFRP Rebar?
● Advantage of FRP rebar?
● FRP Rebar VS Steel Rebar
● FRP Rebar Physical and Mechanical Properties
● FRP Rebar Accessories
● Can FRP Anchor Replace Steel Anchor?
● FRP Anchor Application
● FRP Rebar Surface
